1. What are the reasons for the deviation of the belt conveyor and how to deal with it?1. What are the reasons for the deviation of the belt conveyor and how to deal with it?
Reasons: 1) The drum and the shaft of the support shaft stick to coal.
2) The coal drop point of the falling coal pipe is not correct.
3) The tension of the tensioning device is unbalanced.
4) The belt interface is not correct.
5) The center of the head and tail rollers is not correct.
6) The weight is too light and the tension is not enough.
7) The axis of the tape support roller is not perpendicular to the center line of the tape machine.
Approach:
1) Stop the coal removal.
2) Adjust the coal drop point.
3) Adjust the tensioning device.
4) Re-bond the belt.
5) Adjust the head and tail drum and the frame. 6) Contact the maintenance to adjust the weight of the weight.
7) Re-adjust the roller and adjust the roller to the forward direction of the tape.

2. What is the cause and treatment of the belt slip?
Reason: 1) The belt is overloaded.
2) The non-working surface of the belt is water, oil and ice.
3) The initial tension is too small.
4) The friction between the tape and the roller is not enough
5) The startup speed is too fast.
Approach:
1) Reduce the load.
2) Spread the rosin on the drum.
3) Adjust the tensioning device to increase the initial tension.
4) Increase the tension.
5) It can be started twice by jog, which can effectively control the slip phenomenon.

4, the reasons for the belt conveyor can not start and how to deal with it?
the reason:
1) The motor loses power.
2) The chain is put into operation and the upper level equipment is not activated.
3) The button is not reset after the local stop. 4), change the roller to get stuck or freeze.
5) The cable switch or the deviation switch is not reset after the action.
6) Some objects are stuck in the falling coal pipe.
7) The fluid coupler fuse is damaged.
8) Excessive coal pressure on the belt.
Approach:
1) Contact the electrician to send power.
2) Unlock the chain or start the upper level device.
3) Reset the stop button.
4) Clean the card.
5) Reset the pull switch or the deviation switch
6) Clean the falling coal pipe.
7) Contact the repair process.
8) Subtract the coal without pressure.
